9230A Series of DC Current Shunts
0
PRODUCT FEATURES
- Extremely Low Self-Heating Effects
- Low Temperature Coefficients
- Low Thermal EMF’s
- Wide Dynamic Range
- Controlled Current Distribution Through the Element
- < 10 ppm Long Term Stability
- Air or Oil Cooled Applications
- 3 New Values, 3000 A, 5000 A and 10,000 A!
- Series Ranges from 10 A to 10,000 A
- 3 Point Current Calibration Provided
- Special Values Available On Request
- Available Forced Convection Option Improves Power Dissipation
Guildline Instruments 9230A SERIES of precision DC current shunts / standards are true 4-terminal devices intended for the precise measurement of DC current. They are constructed using elements made from a Guildline proprietary metal alloy and are supported on an insulating base for mechanical stability.
.
